| Model | SUP-RD801 | Model | SUP-RD802 |
| Application | Solid, strong dust, easy to crystallize | Application | Corrosive liquid |
| Frequency | 6GHz | Frequency | 6GHz |
| Range | 0-20m | Range | 0-20m |
| Accuracy | ±10mm | Accuracy | ±10mm |
| Antenna | Rod antenna(PP/PTFE) | Antenna | Rod antenna(PP/PTFE) |
| Pressure | -0.1~0.3MPa | Pressure | -0.1~01.6MPa |
| Temperature | -40~130ºC | Temperature | -40~130ºC |
| Connection | Thread/flange | Connection | Flange |
| Signal output | 4-20mA, RS 485, HART | Signal output | 4-20mA, RS 485, HART |
| Model | SUP-RD803 | Model | SUP-RD803T |
| Application | With pressure and volatile liquid | Application | With pressure and volatile liquid |
| Frequency | 6GHz | Frequency | 6GHz |
| Range | 0-35m | Range | 0-35m |
| Accuracy | ±10mm | Accuracy | ±10mm |
| Antenna | Rod antenna(PP/PTFE) | Antenna | Rod antenna(PP/PTFE) |
| Pressure | -0.1~4MPa | Pressure | -0.1~0.6MPa |
| Temperature | -40~130ºC | Temperature | -40~130ºC |
| Connection | Flange | Connection | Flange |
| Signal output | 4-20mA, RS 485, HART | Signal output | 4-20mA, RS 485, HART |
| Model | SUP-RD902T | Model | SUP-RD902 |
| Application | Corrosive liquid | Application | Temp,pressure resistance,slight corrosion |
| Frequency | 26GHz | Frequency | 26GHz |
| Range | 0-10m | Range | 0-30m |
| Accuracy | ±5mm | Accuracy | ±5mm |
| Pressure | -0.1~0.3MPa | Pressure | -0.1~0.3MPa |
| Temperature | -40~130ºC | Temperature | -40~130ºC |
| Connection | Thread/flange | Connection | Thread/flange |
| Signal output | 4-20mA, RS 485, HART | Signal output | 4-20mA, RS 485, HART |
| Model | SUP-RD903 | Model | SUP-RD904 |
| Application | Solid, strong dust, easy to crystallize | Application | Solid, strong dust, easy to crystallize |
| Frequency | 26GHz | Frequency | 26GHz |
| Range | 0-70m | Range | 0-80m |
| Accuracy | ±15mm | Accuracy | ±15mm |
| Pressure | -0.1~0.3MPa(flange) | Pressure | -0.1~0.3MPa(flange) |
| -0.1~4.0MPa(flat) | |||
| Temperature | -40~130ºC(250ºC high temp type) | Temperature | -40~130ºC(250ºC high temp type) |
| Connection | Thread/flange | Connection | Thread/flange |
| Signal output | 4-20mA, RS 485, HART | Signal output | 4-20mA, RS 485, HART |
| Model | SUP-RD70 | Model | SUP-RD70 |
| Application | Liquid,solid | Application | Liquid,corrosive liquid |
| Frequency | 500MHz-1.8GHz | Frequency | 500MHz-1.8GHz |
| Range | 0-30m | Range | 0-20m |
| Accuracy | ±10mm | Accuracy | ±10mm |
| Antenna | Rod antenna(PP/PTFE) | Antenna | Rod antenna or PTFE cable antenna |
| Pressure | -0.1~4MPa(flange) | Pressure | -0.1~4MPa(flange) |
| Temperature | -40~130ºC(250ºC high temp type) | Temperature | -40~130ºC(220ºC high temp type) |
| Connection | Thread/flange | Connection | Thread/flange |
| Signal output | 4-20mA, RS 485, HART | Signal output | 4-20mA, RS 485, HART |
Overseas Service Center Address:
Singapore/ Philippines/ Malaysia/ Kroea/ Indonesia/ Germany/ India
FAQ:
Q: How long will you give me the reply?
A: we will contact you in 3 hours as soon as we can.
Q:Could I visit your factory?
A: Sincerely invite you to visit our factory,Our factory and office are all in Hangzhou,Zhejiang.
Q: Do you provide samples ?
A: Yes,we have materials in stock to help you to get the samples as soon as we can.
Q: How about the quality of the managements ?
A: We have a complete quality control system , all of our products will be fully pre-inspection by QC departments before
shipping to you . We have the certification of ISO,CE we could send the certification test of our company to you.
Q: What is your terms of payment ?
A: We could accept T/T, Paypal, WU ,Credit Assurance
Q: What is the warranty for your product ?
A: Warranty: 2 years, Lifetime maintenance.
Q: How soon can you arrange the production?
A: Once getting your product confirmation and receiving your payment, we will arrange the production immediately.
For some products we have it in stock.
Q: Could you provide me the shortest lead time?
A: For somre standard products we have it in stock . Pls tell me your detailed requirements,
we will send to you as early as we can.
